Overview

GPI-441 is a single port, 90W Power Injector for remote PoE++ devices. This device is a simple and inexpensive solution for Powered Devices in remote areas or at locations where there is no power sourcing equipment. It withstands temperatures between  0°C-40°C (32°F-104°F). It uses LED indicators to show when the device is in operation. By generating up to 90W, GPI-431 supplies remote power for modern applications such as dome surveillance cameras, lights, and smart kiosks.

Features

• One 10/100/1000Base-T port

• 4-Pair 90W PoE (Power/Data)

• Compliant with IEEE802.3, 802.3u, 802.3ab, 802.3af, 802.3at standards

• Automatic detection of connected PoE devices

• IEEE 802.3af/at backward compatible

• Full-Range (100~240VAC) internal power supply

• No Fan, natural cooling, small size, no noise

• CE/FCC compliant

Specifications

Interface

Ports

1 x 10/100/1000 Base-T RJ45 port

LED PanelMode A, Mode B, Power

Power
Input Voltage: 56V DC Max.
User Port Power: 90W Max.
Input Power Voltage and Frequency:100-240V AC, 50 to 60 Hz


Mechanical and Environment

Operating Ambient Temperature:
0°C~40°C (32°F~104°F)

Weight:
530 g (1.17 lb)

Dimension (WxHxD):
180 x 71 x 37 mm (7.08 x 2.80 x 1.46 in)
